TS1872IYDT
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 TS1872 Nickel/Palladium/Gold (Ni/Pd/Au) op amp amplifier circuit 4.9mm 0.15muA 100muV 1600kHz
PDF
/
Buying Options
Total Price: USD $1.66
Unit Price: USD $1.65965
≥1 USD $1.65965
≥10 USD $1.36135
≥100 USD $1.31955
≥500 USD $1.2768
≥1000 USD $1.23405
Inventory: 113821
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q100
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Operational Amplifier
Packing Method TAPE AND REEL
Technology BICMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 1.8V
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number TS1872
Pin Count 8
Output Type Rail-to-Rail
Number of Circuits 2
Operating Supply Current 500μA
Nominal Supply Current 560μA
Output Current 68mA
Slew Rate 0.6V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type General Purpose
Common Mode Rejection Ratio 55 dB
Current - Input Bias 70nA
Voltage - Supply, Single/Dual (±) 1.8V~6V
Output Current per Channel 80mA
Input Offset Voltage (Vos) 100μV
Gain Bandwidth Product 1.8MHz
Unity Gain BW-Nom 1600 kHz
Voltage Gain 97dB
Average Bias Current-Max (IIB) 0.15μA
Low-Offset NO
Frequency Compensation YES
Supply Voltage Limit-Max 7V
Low-Bias NO
Micropower YES
Programmable Power NO
Wideband NO
Power NO
Input Offset Current-Max (IIO) 0.06μA
Dimensions
Height Seated (Max) 1.75mm
Length 4.9mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
