TS1852AIPT
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 TS1852 Tape & Reel (TR) op amp buffer circuit 4.4mm 0.055muA 1mV 600kHz
PDF
/
Buying Options
Total Price: USD $0.49
Unit Price: USD $0.487775
≥1 USD $0.487775
≥10 USD $0.463382
≥100 USD $0.445966
Inventory: 1601
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Subcategory Operational Amplifier
Packing Method TAPE AND REEL
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 2
Supply Voltage 3V
Terminal Pitch 0.65mm
Base Part Number TS1852
Pin Count 8
Output Type Rail-to-Rail
Number of Elements 2
Operating Supply Current 162μA
Nominal Supply Current 170μA
Output Current 46mA
Slew Rate 0.25V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type General Purpose
Common Mode Rejection Ratio 65 dB
Current - Input Bias 16nA
Voltage - Supply, Single/Dual (±) 1.8V~6V
Output Current per Channel 48mA
Input Offset Voltage (Vos) 1mV
Gain Bandwidth Product 630kHz
Unity Gain BW-Nom 600 kHz
Voltage Gain 97dB
Average Bias Current-Max (IIB) 0.055μA
Low-Offset NO
Frequency Compensation YES
Supply Voltage Limit-Max 7V
Low-Bias NO
Micropower YES
Bias Current-Max (IIB) @25C 0.063μA
Programmable Power NO
Wideband NO
Power NO
Dimensions
Length 4.4mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
