TL074CN
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Lead Free Through Hole J-FET BIPOLAR J-FET Amplifier 680mW 100ns 70dB 13V/mus
PDF
/
Buying Options
Total Price: USD $0.79
Unit Price: USD $0.792
≥1 USD $0.792
≥10 USD $0.69784
≥100 USD $0.655776
≥500 USD $0.535216
≥1000 USD $0.497094
≥3000 USD $0.423069
Inventory: 4653
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 14-DIP (0.300, 7.62mm)
Number of Pins 14
Technical
Operating Temperature 0°C~70°C
Packaging Tube
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Operational Amplifier
Technology BIPOLAR
Terminal Position DUAL
Number of Functions 4
Supply Voltage 15V
Base Part Number TL074
Pin Count 14
Number of Channels 4
Operating Supply Current 1.4mA
Nominal Supply Current 2.5mA
Power Dissipation 680mW
Output Current 40mA
Min Input Voltage -12V
Slew Rate 13V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type J-FET
Common Mode Rejection Ratio 70 dB
Current - Input Bias 20pA
Max Input Voltage 15V
Voltage - Supply, Single/Dual (±) 6V~36V ±3V~18V
Output Current per Channel 40mA
Input Offset Voltage (Vos) 10mV
Bandwidth 3MHz
Rise Time 100ns
Neg Supply Voltage-Nom (Vsup) -15V
Unity Gain BW-Nom 3000 kHz
Voltage Gain 106.02dB
Average Bias Current-Max (IIB) 0.02μA
Low-Offset NO
Frequency Compensation YES
Supply Voltage Limit-Max 18V
Voltage - Input Offset 3mV
Low-Bias YES
Bias Current-Max (IIB) @25C 0.0002μA
Dual Supply Voltage 9V
Neg Supply Voltage-Max (Vsup) -18V
Dimensions
Height 5.1mm
Length 20mm
Width 7.1mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
