TL064ACDT
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 TL064 Nickel/Palladium/Gold (Ni/Pd/Au) op amp buffer circuit 8.65mm 0.007muA 6mV 1000kHz
PDF
/
Buying Options
Total Price: USD $0.77
Unit Price: USD $0.7744
≥1 USD $0.7744
≥10 USD $0.69256
≥100 USD $0.657536
≥500 USD $0.540056
≥1000 USD $0.504874
≥3000 USD $0.44616
Inventory: 1118
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 8.65mm
Height Seated (Max) 1.75mm
Technical
Bias Current-Max (IIB) @25C 0.0002μA
Micropower YES
Low-Bias YES
Voltage - Input Offset 3mV
Frequency Compensation YES
Low-Offset NO
Average Bias Current-Max (IIB) 0.007μA
Voltage Gain 75.56dB
Unity Gain BW-Nom 1000 kHz
Neg Supply Voltage-Nom (Vsup) -15V
Bandwidth 1MHz
Input Offset Voltage (Vos) 6mV
Output Current per Channel 20mA
Voltage - Supply, Single/Dual (±) 6V~36V ±3V~18V
Current - Input Bias 30pA
Common Mode Rejection Ratio 80 dB
Amplifier Type J-FET
Architecture VOLTAGE-FEEDBACK
Slew Rate 3.5V/μs
Power Dissipation 680mW
Nominal Supply Current 1mA
Operating Supply Current 200μA
Number of Channels 4
Power Supplies +-15V
Operating Supply Voltage 18V
Pin Count 14
Base Part Number TL064
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 1.27mm
Supply Voltage 15V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Packing Method TAPE AND REEL
Subcategory Operational Amplifier
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Number of Pins 14
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Factory Lead Time 10 Weeks
