MC4558CN
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 MC4558 Matte Tin (Sn) - annealed op amp amplifier circuit 9.8mm 0.5muA 9V 5500kHz
PDF
/
Buying Options
Total Price: USD $0.28
Unit Price: USD $0.27645
≥1 USD $0.27645
≥10 USD $0.22705
≥100 USD $0.2204
≥500 USD $0.2128
≥1000 USD $0.20615
Inventory: 1397
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm)
Number of Pins 8
Weight 4.535924g
Technical
Operating Temperature 0°C~70°C
Packaging Tube
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Operational Amplifier
Technology BIPOLAR
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 2
Supply Voltage 15V
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number MC4558
Pin Count 8
Qualification Status Not Qualified
Power Supplies +-15V
Number of Channels 2
Operating Supply Current 2.3mA
Nominal Supply Current 4.5mA
Power Dissipation 680mW
Output Current 20mA
Slew Rate 2.2V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type General Purpose
Common Mode Rejection Ratio 70 dB
Current - Input Bias 50nA
Voltage - Supply, Single/Dual (±) ±2V~20V
Output Current per Channel 20mA
Input Offset Voltage (Vos) 5mV
Bandwidth 5.5MHz
Neg Supply Voltage-Nom (Vsup) -15V
Unity Gain BW-Nom 5500 kHz
Voltage Gain 106.02dB
Average Bias Current-Max (IIB) 0.5μA
Low-Offset NO
Frequency Compensation YES
Voltage - Input Offset 1mV
Bias Current-Max (IIB) @25C 0.4μA
Dual Supply Voltage 9V
Dimensions
Height 3.3mm
Length 9.8mm
Width 7.1mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
