LMV324IPT
RoHS
RoHS compliant
RoHS compliantPackage 14-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 LMV324 Nickel/Palladium/Gold (Ni/Pd/Au) op amp buffer circuit 5.1mm 0.095muA 100muV 1300kHz
PDF
/
Buying Options
Total Price: USD $0.34
Unit Price: USD $0.34466
≥1 USD $0.34466
≥10 USD $0.32515
≥100 USD $0.30674
≥500 USD $0.28938
≥1000 USD $0.273
≥3000 USD $0.25755
Inventory: 9519
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-TSSOP (0.173, 4.40mm Width)
Number of Pins 14
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Operational Amplifier
Packing Method TR
Technology BICMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 4
Supply Voltage 5V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number LMV324
Pin Count 14
Output Type Rail-to-Rail
Power Supplies 2.7/5V
Number of Channels 4
Operating Supply Current 162μA
Nominal Supply Current 162μA
Output Current 46mA
Slew Rate 0.45V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type General Purpose
Common Mode Rejection Ratio 65 dB
Current - Input Bias 16nA
Voltage - Supply, Single/Dual (±) 2.7V~6V
Output Current per Channel 48mA
Input Offset Voltage (Vos) 100μV
Bandwidth 1MHz
Gain Bandwidth Product 1.3MHz
Unity Gain BW-Nom 1300 kHz
Voltage Gain 97dB
Average Bias Current-Max (IIB) 0.095μA
Low-Offset NO
Frequency Compensation NO
Supply Voltage Limit-Max 7V
Low-Bias NO
Micropower NO
Max Frequency 100kHz
Bias Current-Max (IIB) @25C 0.063μA
Programmable Power NO
Power NO
Input Offset Current-Max (IIO) 0.025μA
Max Junction Temperature (Tj) 150°C
Dimensions
Height 1.2mm
Length 5.1mm
Width 4.5mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
