MC33071D
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Non-RoHS Compliant R-PDSO-G8 MATTE TIN Tube op amp buffer circuit 4.9mm 0.7muA -22V 4500kHz
PDF
/
Inventory: 2790
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Length 4.9mm
Technical
Neg Supply Voltage-Max (Vsup) -22V
Current - Output / Channel 30mA
Voltage - Input Offset 1mV
Supply Voltage Limit-Max 22V
Average Bias Current-Max (IIB) 0.7μA
Unity Gain BW-Nom 4500 kHz
Neg Supply Voltage-Nom (Vsup) -15V
Gain Bandwidth Product 4.5MHz
Voltage - Supply, Single/Dual (±) 3V~44V ±1.5V~22V
Current - Input Bias 100nA
Common Mode Rejection Ratio 97 dB
Amplifier Type General Purpose
Slew Rate 13V/μs
Current - Supply 1.9mA
Number of Circuits 1
JESD-30 Code R-PDSO-G8
Pin Count 8
Time@Peak Reflow Temperature-Max (s) 40
Supply Voltage 15V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Subcategory Operational Amplifier
Terminal Finish MATTE TIN
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
