NCV34074VDR2G
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant e3 Tin (Sn) Tape & Reel (TR) op amp buffer circuit 8.65mm 0.7muA 1.5mV 4500kHz
PDF
/
Buying Options
Total Price: USD $0.93
Unit Price: USD $0.9291
≥1 USD $0.9291
≥10 USD $0.76285
≥100 USD $0.7391
≥500 USD $0.71535
≥1000 USD $0.6916
≥3000 USD $0.6194
Inventory: 7130
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154, 3.90mm Width)
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
Published 2006
Series Automotive, AEC-Q100
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
Terminal Finish Tin (Sn)
Subcategory Operational Amplifier
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 4
Supply Voltage 15V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Circuits 4
Operating Supply Current 1.9mA
Slew Rate 13V/μs
Amplifier Type General Purpose
Common Mode Rejection Ratio 97 dB
Current - Input Bias 100nA
Voltage - Supply, Single/Dual (±) 3V~44V ±1.5V~22V
Output Current per Channel 30mA
Input Offset Voltage (Vos) 1.5mV
Gain Bandwidth Product 4.5MHz
Neg Supply Voltage-Nom (Vsup) -15V
Unity Gain BW-Nom 4500 kHz
Average Bias Current-Max (IIB) 0.7μA
Supply Voltage Limit-Max 22V
Neg Supply Voltage-Max (Vsup) -22V
Dimensions
Height Seated (Max) 1.75mm
Length 8.65mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
