MC74VHCT125ADR2
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Contains Lead Not Qualified GULL WING CMOS op amp amplifier circuit 500mW 7.5ns 50pF 125C
PDF
/
Buying Options
Total Price: USD $0.25
Unit Price: USD $0.2489
≥1 USD $0.2489
≥10 USD $0.20425
≥100 USD $0.19855
≥500 USD $0.1919
≥1000 USD $0.18525
Inventory: 1266
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Package / Case SOIC
Number of Pins 14
Technical
Packaging Tape and Reel
JESD-609 Code e0
Moisture Sensitivity Level (MSL) 1
Number of Terminations 14
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Subcategory Bus Driver/Transceivers
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Number of Functions 4
Supply Voltage 5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 30
Number of Output Lines 3
Power Supply Current-Max (ICC) 1.65mA
Control Type ENABLE LOW
Low Level Output Current 8mA
High Level Output Current -8mA
Prop. Delay@Nom-Sup 10.5 ns
Max I(ol) 0.008 A
Logic IC Type BUS DRIVER
Logic Function Buffer
Family AHCT/VHCT
Turn On Delay Time 18 ns
Quiescent Current 2μA
Propagation Delay 7.5 ns
Number of Bits 1
Number of Ports 2
Load Capacitance 50pF
Power Dissipation-Max 500mW
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Number of Channels 4
Temperature Grade MILITARY
Power Supplies 5V
Polarity Non-Inverting
Qualification Status Not Qualified
Pin Count 14
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Dimensions
Length 8.65mm
Height Seated (Max) 1.75mm
