NTE948
RoHS
/
Package DIP
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Not Qualified OPERATIONAL AMPLIFIER COMMERCIAL DUAL op amp amplifier circuit 70dB 0.5V/mus 70C 1MHz
PDF
/
Inventory: 8221
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Package / Case DIP
Number of Pins 14
Weight 72.574779g
Technical
JESD-609 Code e0
Pbfree Code no
ECCN Code EAR99
Terminal Finish TIN LEAD
Max Operating Temperature 70°C
Min Operating Temperature 0°C
Subcategory Operational Amplifier
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 4
Supply Voltage 15V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 14
Qualification Status Not Qualified
Operating Supply Voltage 9V
Temperature Grade COMMERCIAL
Nominal Supply Current 2.4mA
Current - Output 25mA
Min Input Voltage 12V
Slew Rate 0.5 V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type OPERATIONAL AMPLIFIER
Common Mode Rejection Ratio 70 dB
Current - Input Bias 30nA
Input Offset Voltage (Vos) 1mV
Bandwidth 1MHz
Gain Bandwidth Product 1MHz
Neg Supply Voltage-Nom (Vsup) -15V
Low-Offset NO
Frequency Compensation YES
Max Dual Supply Voltage 18V
Low-Bias NO
Micropower NO
Bias Current-Max (IIB) @25C 0.2μA
Programmable Power NO
Dual Supply Voltage 15V
Power NO
Number of Amplifiers 4
Dimensions
Height 12.7mm
Length 19.95mm
Width 76.2mm
Compliance
RoHS Status RoHS Compliant
