LMC6584AIM
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Contains Lead Not Qualified GULL WING OPERATIONAL AMPLIFIER op amp amplifier circuit 82dB 1.2V/mus 85C 1200kHz
PDF
/
Inventory: 5584
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 3.9mm
Length 8.65mm
Height Seated (Max) 1.75mm
Technical
Voltage Gain-Min 10000
Input Offset Voltage-Max 1000μV
Low-Bias YES
Supply Voltage Limit-Max 12V
Frequency Compensation YES
Low-Offset NO
Unity Gain BW-Nom 1200 kHz
Common Mode Rejection Ratio 82 dB
Amplifier Type OPERATIONAL AMPLIFIER
Architecture VOLTAGE-FEEDBACK
Slew Rate 1.2 V/μs
Supply Current-Max 7.2mA
Number of Circuits 4
Temperature Grade INDUSTRIAL
Power Supplies 1.8/10V
Operating Temperature (Max) 85°C
Qualification Status Not Qualified
Pin Count 14
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Supply Voltage 10V
Number of Functions 4
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Packing Method RAIL
Subcategory Operational Amplifiers
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 14
JESD-609 Code e0
Physical
Number of Pins 14
Surface Mount YES
Package / Case SOIC
