TC1035ECHTR
RoHS
RoHS compliant
RoHS compliantPackage SOT-23-6
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 TC1035 Matte Tin (Sn) op amp amplifier circuit 2.9mm 0.008mA 500muV 90kHz
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.8056
≥1 USD $0.8056
≥10 USD $0.6612
≥100 USD $0.6403
≥500 USD $0.62035
≥1000 USD $0.59945
Inventory: 96
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SOT-23-6
Number of Pins 6
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2015
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Operational Amplifiers
Packing Method TAPE AND REEL
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 0.95mm
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number TC1035
Pin Count 6
Qualification Status Not Qualified
Output Type Rail-to-Rail
Operating Supply Voltage 5V
Number of Elements 1
Operating Supply Current 6μA
Supply Current-Max 0.008mA
Slew Rate 0.035V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type General Purpose
Common Mode Rejection Ratio 70 dB
Current - Input Bias 50pA
Voltage - Supply, Single/Dual (±) 1.8V~5.5V
Output Current per Channel 4mA
Input Offset Voltage (Vos) 500μV
Gain Bandwidth Product 90kHz
Unity Gain BW-Nom 90 kHz
Voltage Gain 100dB
Power Supply Rejection Ratio (PSRR) 80dB
Low-Offset NO
Frequency Compensation YES
Supply Voltage Limit-Max 6V
Voltage - Input Offset 100μV
Low-Bias YES
Micropower YES
Programmable Power NO
Wideband NO
Dimensions
Length 2.9mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
