MCP6V07T-E/SN
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 MCP6V07 Matte Tin (Sn) - annealed op amp amplifier circuit 4.9mm 0.005muA 3muV 1300kHz
PDF
/
Buying Options
Total Price: USD $1.47
Unit Price: USD $1.4725
≥1 USD $1.4725
≥10 USD $1.2084
≥100 USD $1.1704
≥500 USD $1.13335
≥1000 USD $1.09535
Inventory: 1135
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 4.9mm
Height Seated (Max) 1.75mm
Technical
Micropower YES
Low-Bias YES
Supply Voltage Limit-Max 6.5V
Frequency Compensation YES
Low-Offset YES
Power Supply Rejection Ratio (PSRR) 125dB
Average Bias Current-Max (IIB) 0.005μA
Voltage Gain 158dB
Unity Gain BW-Nom 1300 kHz
Gain Bandwidth Product 1.3MHz
Input Offset Voltage (Vos) 3μV
Output Current per Channel 22mA
Voltage - Supply, Single/Dual (±) 1.8V~5.5V
Current - Input Bias 6pA
Common Mode Rejection Ratio 120 dB
Amplifier Type Zero-Drift
Architecture VOLTAGE-FEEDBACK
Slew Rate 0.5V/μs
Output Current 22mA
Nominal Supply Current 300μA
Operating Supply Current 300μA
Number of Elements 2
Output Type Rail-to-Rail
Pin Count 8
Base Part Number MCP6V07
Time@Peak Reflow Temperature-Max (s) 40
Supply Voltage 1.8V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Packing Method TAPE AND REEL
Subcategory Operational Amplifier
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
Alternative Model
