MCP662-E/MS
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant e3 MCP662 Matte Tin (Sn) - annealed op amp buffer circuit 3mm 6pA 8mV 60000kHz
PDF
/
Buying Options
Total Price: USD $1.43
Unit Price: USD $1.4256
≥1 USD $1.4256
≥10 USD $1.1968
≥100 USD $1.0824
Inventory: 466
Minimum: 1
-
+
Technical Details
Technical
Slew Rate 32V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type General Purpose
Common Mode Rejection Ratio 64 dB
Current - Input Bias 6pA
Voltage - Supply, Single/Dual (±) 2.5V~5.5V ±1.25V~2.75V
Input Offset Voltage (Vos) 8mV
Output Current 90mA
Nominal Supply Current 6mA
Number of Circuits 2
Power Supplies 3/5V
Number of Elements 2
Output Type Rail-to-Rail
Qualification Status Not Qualified
Pin Count 8
Base Part Number MCP662
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.65mm
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Operational Amplifier
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2012
Packaging Tube
Operating Temperature -40°C~125°C
Wideband NO
Programmable Power NO
Micropower NO
Low-Bias YES
Voltage - Input Offset 1.8mV
Supply Voltage Limit-Max 6.5V
Frequency Compensation YES
Low-Offset NO
Power Supply Rejection Ratio (PSRR) 61dB
Voltage Gain 126dB
Unity Gain BW-Nom 60000 kHz
Gain Bandwidth Product 60MHz
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 3mm
Height Seated (Max) 1.1mm
