MCP6273T-E/SN
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 MCP6273 Matte Tin (Sn) op amp amplifier circuit 4.9mm 0.005muA 3mV 2000kHz
PDF
/
Buying Options
Total Price: USD $6.26
Unit Price: USD $6.258693
≥1 USD $6.258693
≥10 USD $5.904432
≥100 USD $5.570214
≥500 USD $5.254914
≥1000 USD $4.957471
Inventory: 1395
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2008
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Operational Amplifier
Packing Method TAPE AND REEL
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number MCP6273
Pin Count 8
Output Type Rail-to-Rail
Number of Elements 1
Power Supplies 2.5/5V
Operating Supply Current 170μA
Nominal Supply Current 170μA
Output Current 25mA
Slew Rate 0.9V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type General Purpose
Common Mode Rejection Ratio 70 dB
Current - Input Bias 1pA
Voltage - Supply, Single/Dual (±) 2V~6V
Output Current per Channel 25mA
Input Offset Voltage (Vos) 3mV
Gain Bandwidth Product 2MHz
Unity Gain BW-Nom 2000 kHz
Voltage Gain 110dB
Average Bias Current-Max (IIB) 0.005μA
Power Supply Rejection Ratio (PSRR) 70dB
Low-Offset NO
Frequency Compensation YES
Supply Voltage Limit-Max 7V
Low-Bias YES
Micropower YES
Programmable Power NO
Wideband NO
Dimensions
Length 4.9mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
