MCP6071T-E/SN
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 MCP6071 Matte Tin (Sn) - annealed op amp amplifier circuit 4.9mm 0.005muA 150muV 1200kHz
PDF
/
Buying Options
Total Price: USD $0.77
Unit Price: USD $0.7656
≥1 USD $0.7656
≥10 USD $0.6424
≥100 USD $0.572
Inventory: 996
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 4.9mm
Technical
Wideband NO
Programmable Power NO
Micropower YES
Low-Bias YES
Supply Voltage Limit-Max 7V
Frequency Compensation YES
Low-Offset YES
Power Supply Rejection Ratio (PSRR) 70dB
Average Bias Current-Max (IIB) 0.005μA
Voltage Gain 115dB
Unity Gain BW-Nom 1200 kHz
Gain Bandwidth Product 1.2MHz
Input Offset Voltage (Vos) 150μV
Output Current per Channel 28mA
Voltage - Supply, Single/Dual (±) 1.8V~6V
Current - Input Bias 1pA
Common Mode Rejection Ratio 72 dB
Amplifier Type General Purpose
Architecture VOLTAGE-FEEDBACK
Slew Rate 0.5V/μs
Output Current 28mA
Nominal Supply Current 110μA
Operating Supply Current 110μA
Power Supplies 2/5V
Number of Elements 1
Output Type Rail-to-Rail
Pin Count 8
Base Part Number MCP6071
Time@Peak Reflow Temperature-Max (s) 40
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Packing Method TAPE AND REEL
Subcategory Operational Amplifier
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 21 Weeks
