MCP6071T-E/OT
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 MCP6071 Matte Tin (Sn) - annealed op amp amplifier circuit 3.1mm 1pA 150muV 1200kHz
PDF
/
Buying Options
Total Price: USD $0.7
Unit Price: USD $0.704
≥1 USD $0.704
≥10 USD $0.5808
≥100 USD $0.5368
Inventory: 674
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 23 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Number of Pins 5
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2005
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Operational Amplifier
Packing Method TAPE AND REEL
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number MCP6071
Pin Count 5
Output Type Rail-to-Rail
Number of Channels 1
Nominal Supply Current 110μA
Output Current 28mA
Current - Supply 110μA
Slew Rate 0.5V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type General Purpose
Common Mode Rejection Ratio 72 dB
Current - Input Bias 1pA
Voltage - Supply, Single/Dual (±) 1.8V~6V
Input Offset Voltage (Vos) 150μV
Bandwidth 1.2MHz
Unity Gain BW-Nom 1200 kHz
Voltage Gain 115dB
Power Supply Rejection Ratio (PSRR) 70dB
Low-Offset YES
Frequency Compensation YES
Supply Voltage Limit-Max 7V
Low-Bias YES
Micropower YES
Programmable Power NO
Dimensions
Height 1.3mm
Length 3.1mm
Width 1.8mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
