MCP6064T-E/SL
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 MCP6064 Matte Tin (Sn) - annealed op amp amplifier circuit 8.65mm 0.005muA 150muV 730kHz
PDF
/
Buying Options
Total Price: USD $15.78
Unit Price: USD $15.777722
≥1 USD $15.777722
≥10 USD $14.884649
≥100 USD $14.042117
≥500 USD $13.24728
≥1000 USD $12.497439
Inventory: 4839
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 8.65mm
Height Seated (Max) 1.75mm
Technical
Wideband NO
Programmable Power NO
Bias Current-Max (IIB) @25C 0.0001μA
Micropower YES
Low-Bias YES
Supply Voltage Limit-Max 7V
Frequency Compensation YES
Low-Offset YES
Power Supply Rejection Ratio (PSRR) 70dB
Average Bias Current-Max (IIB) 0.005μA
Voltage Gain 115dB
Unity Gain BW-Nom 730 kHz
Gain Bandwidth Product 730kHz
Input Offset Voltage (Vos) 150μV
Voltage - Supply, Single/Dual (±) 1.8V~6V
Current - Input Bias 1pA
Common Mode Rejection Ratio 72 dB
Amplifier Type General Purpose
Architecture VOLTAGE-FEEDBACK
Slew Rate 0.25V/μs
Current - Supply 60μA
Output Current 27mA
Nominal Supply Current 60μA
Power Supplies 2/5V
Number of Elements 4
Output Type Rail-to-Rail
Pin Count 14
Base Part Number MCP6064
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 1.27mm
Supply Voltage 3V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Packing Method TAPE AND REEL
Subcategory Operational Amplifier
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 1998
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 14
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
Alternative Model
