MAX9911EXT
RoHS
/
Package /
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Not Qualified GULL WING OPERATIONAL AMPLIFIER BICMOS op amp amplifier circuit 80dB 0.1V/us 85C 200kHz
PDF
/
Buying Options
Total Price: USD $4.83
Unit Price: USD $4.82885
≥1 USD $4.82885
≥10 USD $3.9615
≥100 USD $3.838
≥500 USD $3.7145
≥1000 USD $3.59005
Inventory: 1585
Minimum: 1
-
+
Technical Details
Physical
Surface Mount YES
Technical
Packaging Cut Tape
JESD-609 Code e4
Pbfree Code yes
Moisture Sensitivity Level (MSL) 1
Number of Terminations 6
ECCN Code EAR99
Terminal Finish Gold/Nickel (Au/Ni)
HTS Code 8542.33.00.01
Subcategory Operational Amplifier
Packing Method TAPE AND REEL
Technology BICMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 1.8V
Terminal Pitch 0.65mm
Reach Compliance Code compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 6
JESD-30 Code R-PDSO-G6
Qualification Status Not Qualified
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Power Supplies 2/5V
Temperature Grade INDUSTRIAL
Supply Current-Max 0.0055mA
Slew Rate 0.1 V/us
Architecture VOLTAGE-FEEDBACK
Amplifier Type OPERATIONAL AMPLIFIER
Common Mode Rejection Ratio 80 dB
Unity Gain BW-Nom 200 kHz
Average Bias Current-Max (IIB) 0.00001μA
Low-Offset NO
Frequency Compensation YES
Supply Voltage Limit-Max 6V
Low-Bias YES
Micropower YES
Bias Current-Max (IIB) @25C 0.00001μA
Programmable Power NO
Input Offset Voltage-Max 1000μV
Wideband NO
Power NO
Voltage Gain-Min 10000
Dimensions
Height Seated (Max) 1.1mm
Length 2mm
Width 1.25mm
Compliance
RoHS Status RoHS Compliant
