OP227EJ
RoHS
/
Package 14-CDIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Non-RoHS Compliant R-CDIP-T14 OP227 Tin/Lead (Sn/Pb) op amp amplifier circuit 19.43mm 0.04muA -15V 8000kHz
PDF
/
Inventory: 6053
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Length 19.43mm
Height Seated (Max) 5.08mm
Technical
Common-mode Reject Ratio-Min 114 dB
Voltage Gain-Min 1000000
Bias Current-Max (IIB) @25C 0.04μA
Voltage - Input Offset 20μV
Frequency Compensation YES
Low-Offset YES
Average Bias Current-Max (IIB) 0.04μA
Unity Gain BW-Nom 8000 kHz
Neg Supply Voltage-Nom (Vsup) -15V
Gain Bandwidth Product 8MHz
Voltage - Supply, Single/Dual (±) ±4V~18V
Current - Input Bias 10nA
Common Mode Rejection Ratio 126 dB
Amplifier Type General Purpose
Architecture VOLTAGE-FEEDBACK
Slew Rate 2.8V/μs
Number of Circuits 2
Power Supplies +-15V
Qualification Status Not Qualified
JESD-30 Code R-CDIP-T14
Pin Count 14
Base Part Number OP227
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 15V
Number of Functions 2
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology BIPOLAR
Subcategory Operational Amplifier
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Published 2005
Packaging Tube
Operating Temperature -25°C~85°C
Physical
Surface Mount NO
Package / Case 14-CDIP (0.300, 7.62mm)
Mounting Type Through Hole
