LTC6240HVHS8#PBF
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 LTC6240 Matte Tin (Sn) op amp buffer circuit 4.9mm 0.0025muA 40muV 12000kHz
PDF
/
Buying Options
Total Price: USD $4.69
Unit Price: USD $4.6904
≥1 USD $4.6904
≥10 USD $4.20992
≥100 USD $3.979712
≥500 USD $3.448984
≥1000 USD $3.272104
≥3000 USD $2.936067
Inventory: 372
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status PRODUCTION (Last Updated: 2 weeks ago)
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Number of Pins 8
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Published 2010
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Operational Amplifier
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number LTC6240
Pin Count 8
Qualification Status Not Qualified
Output Type Rail-to-Rail
Number of Elements 1
Power Supplies 3/5/+-5V
Number of Circuits 1
Operating Supply Current 2.7mA
Slew Rate 10V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type General Purpose
Common Mode Rejection Ratio 78 dB
Current - Input Bias 0.5pA
Voltage - Supply, Single/Dual (±) 2.8V~11V ±1.4V~5.5V
Output Current per Channel 35mA
Input Offset Voltage (Vos) 40μV
Neg Supply Voltage-Nom (Vsup) -5V
Unity Gain BW-Nom 12000 kHz
Voltage Gain 124.08dB
Average Bias Current-Max (IIB) 0.0025μA
Power Supply Rejection Ratio (PSRR) 78dB
Low-Offset YES
Frequency Compensation YES
Supply Voltage Limit-Max 6V
Voltage - Input Offset 60μV
Low-Bias YES
Bias Current-Max (IIB) @25C 0.000075μA
Neg Supply Voltage-Max (Vsup) -6V
Nominal Gain Bandwidth Product 18MHz
Dimensions
Length 4.9mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
