LTC6091HUFE#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 32-WFQFN Exposed Pad, 16 Leads
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant R-PQCC-N16 LTC6091 Matte Tin (Sn) op amp amplifier circuit 6mm 0.0008muA -75V 12000kHz
PDF
/
Buying Options
Total Price: USD $15.98
Unit Price: USD $15.9808
≥1 USD $15.9808
≥10 USD $14.68368
≥100 USD $14.075072
≥500 USD $12.401224
≥1000 USD $11.792598
≥3000 USD $11.031786
Inventory: 1143
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 6mm
Height Seated (Max) 0.8mm
Technical
Neg Supply Voltage-Max (Vsup) -75V
Voltage - Input Offset 330μV
Supply Voltage Limit-Max 75V
Average Bias Current-Max (IIB) 0.0008μA
Unity Gain BW-Nom 12000 kHz
Neg Supply Voltage-Nom (Vsup) -15V
Gain Bandwidth Product 12MHz
Voltage - Supply, Single/Dual (±) 9.5V~140V ±4.75V~70V
Current - Input Bias 3pA
Common Mode Rejection Ratio 126 dB
Amplifier Type General Purpose
Slew Rate 21V/μs
Current - Supply 2.8mA
Number of Circuits 2
Output Type Rail-to-Rail
JESD-30 Code R-PQCC-N16
Pin Count 16
Base Part Number LTC6091
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Supply Voltage 15V
Number of Functions 2
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position QUAD
Technology CMOS
Subcategory Operational Amplifier
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2015
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Surface Mount YES
Package / Case 32-WFQFN Exposed Pad, 16 Leads
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 20 Weeks
