LTC1152CN8#PBF
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant R-PDIP-T8 LTC1152 Matte Tin (Sn) op amp buffer circuit 3.937mm 10pA 5V 700kHz
PDF
/
Buying Options
Total Price: USD $9.81
Unit Price: USD $9.812
≥1 USD $9.812
≥10 USD $8.86688
≥100 USD $8.454336
≥500 USD $7.340784
≥1000 USD $7.010854
≥3000 USD $6.39225
Inventory: 164
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 3.937mm
Technical
Low-Bias YES
Voltage - Input Offset 1μV
Frequency Compensation YES
Low-Offset YES
Unity Gain BW-Nom 700 kHz
Gain Bandwidth Product 700kHz
Voltage - Supply, Single/Dual (±) 2.7V~14V ±1.35V~7V
Current - Input Bias 10pA
Common Mode Rejection Ratio 130 dB
Amplifier Type Zero-Drift
Architecture VOLTAGE-FEEDBACK
Slew Rate 0.5V/μs
Current - Supply 2.2mA
Number of Circuits 1
Output Type Rail-to-Rail
Qualification Status Not Qualified
JESD-30 Code R-PDIP-T8
Pin Count 8
Base Part Number LTC1152
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology CMOS
Subcategory Operational Amplifier
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series C-Load?
Published 1996
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Surface Mount NO
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Supply Chain
Factory Lead Time 8 Weeks
