LT6600IDF-2.5
RoHS
/
Package 12-WFDFN Exposed Pad
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Not Qualified GULL WING Surface Mount Differential op amp buffer circuit 63dB -40C~85C -5.5V 15muA
PDF
/
Buying Options
Total Price: USD $9.29
Unit Price: USD $9.293601
≥1 USD $9.293601
≥10 USD $8.767549
≥100 USD $8.27127
≥500 USD $7.803083
≥1000 USD $7.361401
Inventory: 1173
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 4mm
Length 4mm
Height Seated (Max) 0.8mm
Technical
Neg Supply Voltage-Max (Vsup) -5.5V
Voltage - Input Offset 5mV
Supply Voltage Limit-Max 5.5V
Neg Supply Voltage-Nom (Vsup) -5V
Voltage - Supply, Single/Dual (±) 3V~11V ±1.5V~5.5V
Current - Input Bias 15μA
Common Mode Rejection Ratio 63 dB
Amplifier Type Differential
Current - Supply 28mA
Number of Circuits 1
Power Supplies 3/5/+-5V
Qualification Status Not Qualified
Pin Count 12
Base Part Number LT6600
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.5mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Operational Amplifier
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 12
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 12-WFDFN Exposed Pad
Mounting Type Surface Mount
