LT1920IS8
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Non-RoHS Compliant R-PDSO-G8 LT1920 Tin/Lead (Sn/Pb) op amp buffer circuit 4.9025mm 0.002muA -20V 1MHz
PDF
/
Buying Options
Total Price: USD $40.27
Unit Price: USD $40.2724
≥1 USD $40.2724
≥10 USD $33.04385
≥100 USD $32.0112
≥500 USD $30.97855
≥1000 USD $29.9459
Inventory: 506
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Length 4.9025mm
Technical
Non-linearity-Max 0.003%
Common-mode Reject Ratio-Min 75 dB
Voltage Gain-Min 1
Neg Supply Voltage-Max (Vsup) -20V
-3db Bandwidth 1MHz
Current - Output / Channel 27mA
Voltage - Input Offset 30μV
Supply Voltage Limit-Max 20V
Average Bias Current-Max (IIB) 0.002μA
Neg Supply Voltage-Nom (Vsup) -15V
Gain Bandwidth Product 1MHz
Voltage - Supply, Single/Dual (±) 4.6V~36V ±2.3V~18V
Current - Input Bias 500pA
Amplifier Type Instrumentation
Slew Rate 1.2V/μs
Current - Supply 900μA
Number of Circuits 1
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G8
Pin Count 8
Base Part Number LT1920
Time@Peak Reflow Temperature-Max (s) 20
Reach Compliance Code not_compliant
Supply Voltage 15V
Number of Functions 1
Peak Reflow Temperature (Cel) 235
Terminal Form GULL WING
Terminal Position DUAL
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e0
Published 1999
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
