CS3001-IS
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Not Qualified GULL WING OPERATIONAL AMPLIFIER BIPOLAR op amp buffer circuit 115dB 5V/mus 85C 300dB
PDF
/
Buying Options
Total Price: USD $1.54
Unit Price: USD $1.54
≥1 USD $1.54
Inventory: 3019
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Technical
Min Dual Supply Voltage 1.35V
Max Dual Supply Voltage 3.35V
Voltage Gain 300dB
Input Offset Voltage (Vos) 10μV
Current - Input Bias 1nA
Common Mode Rejection Ratio 115 dB
Amplifier Type OPERATIONAL AMPLIFIER
Slew Rate 5 V/μs
Nominal Supply Current 2.8mA
Number of Channels 1
Temperature Grade INDUSTRIAL
Power Supplies 3/5V
Operating Supply Voltage 3.35V
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G8
Pin Count 8
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Subcategory Instrumentation Amplifiers
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 8
JESD-609 Code e0
Physical
Surface Mount YES
Package / Case SOIC
