PA61
RoHS
RoHS compliant
RoHS compliantPackage TO-3-8
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
RoHS Compliant EAR99 PA61 Nickel (Ni) op amp amplifier circuit 0.03muA 2mV 1000kHz 1MHz
PDF
/
Buying Options
Total Price: USD $9.68
Unit Price: USD $9.67765
≥1 USD $9.67765
≥10 USD $7.94105
≥100 USD $7.69215
≥500 USD $7.4442
≥1000 USD $7.19625
Inventory: 1809
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Common-mode Reject Ratio-Min 74 dB
Voltage Gain-Min 63000
Power YES
Neg Supply Voltage-Max (Vsup) -45V
Bias Current-Max (IIB) @25C 0.03μA
Supply Voltage Limit-Max 45V
Frequency Compensation YES
Low-Offset NO
Average Bias Current-Max (IIB) 0.03μA
Unity Gain BW-Nom 1000 kHz
Neg Supply Voltage-Nom (Vsup) -32V
Gain Bandwidth Product 1MHz
Input Offset Voltage (Vos) 2mV
Output Current per Channel 10A
Voltage - Supply, Single/Dual (±) 20V~90V ±10V~45V
Current - Input Bias 12nA
Common Mode Rejection Ratio 100 dB
Amplifier Type Power
Architecture VOLTAGE-FEEDBACK
Slew Rate 2.8V/μs
Operating Supply Current 3mA
Number of Circuits 1
Power Supplies +-32V
Qualification Status Not Qualified
Pin Count 2
Base Part Number PA61
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 32V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position BOTTOM
Technology HYBRID
Subcategory Operational Amplifier
Terminal Finish Nickel (Ni)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Apex Precision Power?
Packaging Tray
Operating Temperature -25°C~85°C
Physical
Number of Pins 8
Package / Case TO-3-8
Mounting Type Through Hole
Mount Through Hole
Alternative Model
