TPA701DR
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
EAR99 TPA701 Tape & Reel (TR) Short-Circuit and Thermal Protection Shutdown audio amplifier 2.5V 1.58mm 700mW x 1 @ 8Ohm 2.5mA
PDF
/
Buying Options
Total Price: USD $1.08
Unit Price: USD $1.0824
≥1 USD $1.0824
≥10 USD $0.96624
≥100 USD $0.91696
≥500 USD $0.753368
≥1000 USD $0.704211
≥3000 USD $0.622318
Inventory: 1475
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Number of Pins 8
Weight 75.891673mg
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
JESD-609 Code e4
Feature Short-Circuit and Thermal Protection, Shutdown
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type Class AB
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Audio/Video Amplifiers
Max Power Dissipation 725mW
Technology CMOS
Voltage - Supply 2.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Base Part Number TPA701
Pin Count 8
Output Type 1-Channel (Mono)
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 2.5V
Number of Channels 1
Nominal Supply Current 2.5mA
Power Dissipation 725mW
Max Supply Current 2.5mA
Quiescent Current 1.25mA
Output Power 700mW
Supply Type Single
Bandwidth 4 kHz
Gain Bandwidth Product 1.4MHz
Power Supply Rejection Ratio (PSRR) 85dB
Max Output Power 700mW
Max Output Power x Channels @ Load 700mW x 1 @ 8 Ω
Harmonic Distortion 0.5%
Dimensions
Height 1.75mm
Length 4.9mm
Width 3.91mm
Thickness 1.58mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
