TPA311DGN
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width) Exposed Pad
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
EAR99 TPA311 Tube Depop Short-Circuit and Thermal Protection Shutdown audio amplifier 5V 1.02mm 700mW x 1 @ 8Ohm 1.5mA
PDF
/
Buying Options
Total Price: USD $1.37
Unit Price: USD $1.3728
≥1 USD $1.3728
≥10 USD $1.2364
≥100 USD $0.993854
≥500 USD $0.93324
≥1000 USD $0.816578
≥3000 USD $0.676606
Inventory: 133
Minimum: 1
-
+
Technical Details
Physical
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width) Exposed Pad
Surface Mount YES
Number of Pins 8
Weight 18.99418mg
Mounting Type Surface Mount
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
JESD-609 Code e4
Feature Depop, Short-Circuit and Thermal Protection, Shutdown
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type Class AB
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Audio/Video Amplifiers
Max Power Dissipation 2.14W
Technology CMOS
Voltage - Supply 2.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.65mm
Base Part Number TPA311
Pin Count 8
Output Type 1-Channel (Mono)
Operating Supply Voltage 5V
Number of Channels 1
Nominal Supply Current 1.5mA
Power Dissipation 2.14W
Max Supply Current 1.5mA
Quiescent Current 700μA
Output Power 350mW
Supply Type Single
Bandwidth 10 kHz
Gain Bandwidth Product 1.4MHz
Power Supply Rejection Ratio (PSRR) 85dB
Max Output Power 700mW
Max Output Power x Channels @ Load 700mW x 1 @ 8 Ω
Harmonic Distortion 0.5%
Load Impedance 8 Ω
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 6 Weeks
Dimensions
Height 1.1mm
Length 3mm
Width 3mm
Thickness 1.02mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
