TPA302DR
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
GULL WING ROHS3Compliant Contains Lead Surface Mount Amplifier IC Class AB -40C~85C TA 1.5MHz 65dB 300mW
PDF
/
Buying Options
Total Price: USD $1.65
Unit Price: USD $1.65205
≥1 USD $1.65205
≥10 USD $1.35565
≥100 USD $1.31385
≥500 USD $1.2711
≥1000 USD $1.2293
Inventory: 17091
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Number of Pins 8
Weight 75.891673mg
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
JESD-609 Code e4
Feature Short-Circuit and Thermal Protection, Shutdown
Pbfree Code yes
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type Class AB
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Audio/Video Amplifiers
Max Power Dissipation 731mW
Technology CMOS
Voltage - Supply 2.7V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Base Part Number TPA302
Pin Count 8
Output Type 2-Channel (Stereo)
Operating Supply Voltage 5V
Number of Channels 2
Nominal Supply Current 10mA
Power Dissipation 731mW
Max Supply Current 10mA
Output Power 300mW
Supply Type Single
Input Offset Voltage (Vos) 20mV
Bandwidth 20 kHz
Gain Bandwidth Product 1.5MHz
Power Supply Rejection Ratio (PSRR) 65dB
Max Output Power 300mW
Max Output Power x Channels @ Load 300mW x 2 @ 8 Ω
Harmonic Distortion 1%
Dimensions
Height Seated (Max) 1.75mm
Length 4.9mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
