TPA3008D2PHPR
RoHS
RoHS compliant
RoHS compliantPackage 48-PowerTQFP
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
GULL WING ROHS3Compliant Lead Free Surface Mount Amplifier IC Class D -40C~85C TA 22kHz 31.8dB 10W
PDF
/
Buying Options
Total Price: USD $0.83
Unit Price: USD $0.8303
≥1 USD $0.8303
≥10 USD $0.68115
≥100 USD $0.66025
≥500 USD $0.6384
≥1000 USD $0.6175
Inventory: 13355
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1mm
Width 7mm
Length 7mm
Height 1.2mm
Technical
Max Output Power x Channels @ Load 10W x 2 @ 16 Ω
Max Output Power 10W
Gain 31.8 dB
Power Supply Rejection Ratio (PSRR) 76dB
Voltage Gain 31.8dB
Bandwidth 22 kHz
Supply Type Single
Output Power 10W
Power Dissipation 4.3W
Nominal Supply Current 11mA
Number of Channels 2
Supply Voltage-Min (Vsup) 8.5V
Power Supplies 12V
Supply Voltage-Max (Vsup) 18V
Operating Supply Voltage 15V
Output Type 2-Channel (Stereo)
Pin Count 48
Base Part Number TPA3008
Terminal Pitch 0.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Voltage - Supply 8.5V~18V
Technology CMOS
Max Power Dissipation 4.3W
Subcategory Audio/Video Amplifiers
HTS Code 8542.33.00.01
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Class D
ECCN Code EAR99
Number of Terminations 48
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Part Status Active
Pbfree Code yes
Feature Differential Inputs, Mute, Short-Circuit and Thermal Protection, Shutdown
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Weight 134.490138mg
Number of Pins 48
Surface Mount YES
Package / Case 48-PowerTQFP
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
