TPA2005D1TDGNRQ1
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width) Exposed Pad
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
EAR99 TPA2005 Tape & Reel (TR) Differential Inputs Short-Circuit and Thermal Protection Shutdown audio amplifier 2.5V 1.02mm 1.45W x 1 @ 8Ohm 2.8mA
PDF
/
Buying Options
Total Price: USD $1.22
Unit Price: USD $1.2232
≥1 USD $1.2232
≥10 USD $1.09032
≥100 USD $1.035232
≥500 USD $0.850432
≥1000 USD $0.794957
≥3000 USD $0.702504
Inventory: 2586
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.02mm
Width 3mm
Length 3mm
Height 1.1mm
Technical
Harmonic Distortion 10%
Max Output Power x Channels @ Load 1.45W x 1 @ 8 Ω
Max Output Power 1.45W
Gain 20 dB
Power Supply Rejection Ratio (PSRR) -75dB
Bandwidth 20 kHz
Output Power 1.18W
Supply Current-Max 4.5mA
Quiescent Current 2.8mA
Power Dissipation 2.13W
Number of Channels 1
Supply Voltage-Min (Vsup) 2.5V
Power Supplies 3/5V
Supply Voltage-Max (Vsup) 5.5V
Output Type 1-Channel (Mono)
Pin Count 8
Base Part Number TPA2005
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.5V~5.5V
Subcategory Audio/Video Amplifiers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Class D
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
Feature Differential Inputs, Short-Circuit and Thermal Protection, Shutdown
JESD-609 Code e4
Series Automotive, AEC-Q100
Packaging Tape & Reel (TR)
Operating Temperature -40°C~105°C TA
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width) Exposed Pad
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 6 Weeks
