TPA1517DWPR
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width) Exposed Pad
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
EAR99 TPA1517 Tape & Reel (TR) Mute Standby Thermal Protection audio amplifier 9.5V 2.55mm 6W x 2 @ 4Ohm 4A
PDF
/
Buying Options
Total Price: USD $3.42
Unit Price: USD $3.4232
≥1 USD $3.4232
≥10 USD $3.0712
≥100 USD $2.903648
≥500 USD $2.516536
≥1000 USD $2.38751
≥3000 USD $2.14229
Inventory: 3228
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 2.55mm
Width 7.52mm
Length 12.82mm
Height 2.65mm
Technical
Load Impedance 4 Ω
Harmonic Distortion 10%
Max Output Power x Channels @ Load 6W x 2 @ 4 Ω
Max Output Power 6W
Gain 20 dB
Power Supply Rejection Ratio (PSRR) 65dB
Voltage Gain 20dB
Bandwidth 20 kHz
Supply Type Single
Output Power 6W
Quiescent Current 45mA
Max Supply Current 70mA
Power Dissipation 2.94W
Nominal Supply Current 70mA
Number of Channels 2
Supply Voltage-Min (Vsup) 9.5V
Supply Voltage-Max (Vsup) 18V
Operating Supply Voltage 15V
Max Output Current 4A
Output Type 2-Channel (Stereo)
Pin Count 20
Base Part Number TPA1517
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 9.5V~18V
Technology BIPOLAR
Max Power Dissipation 2.94W
Subcategory Audio/Video Amplifiers
Type Class AB
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
Feature Mute, Standby, Thermal Protection
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Weight 506.605978mg
Number of Pins 20
Surface Mount YES
Package / Case 20-SOIC (0.295, 7.50mm Width) Exposed Pad
Mounting Type Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
Alternative Model
