TPA0112PWP
RoHS
RoHS compliant
RoHS compliantPackage 24-TSSOP (0.173, 4.40mm Width) Exposed Pad
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
GULL WING ROHS3Compliant Lead Free Surface Mount Amplifier IC Class AB -40C~85C TA 15kHz 77dB 2.6W
PDF
/
Buying Options
Total Price: USD $2.47
Unit Price: USD $2.46525
≥1 USD $2.46525
≥10 USD $2.02255
≥100 USD $1.95985
≥500 USD $1.8962
≥1000 USD $1.8335
Inventory: 7794
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 7.8mm
Height Seated (Max) 1.2mm
Technical
Harmonic Distortion 5%
Max Output Power x Channels @ Load 2.6W x 2 @ 3 Ω
Max Output Power 2.6W
Power Supply Rejection Ratio (PSRR) 77dB
Bandwidth 15 kHz
Input Offset Voltage (Vos) 25mV
Supply Type Single
Output Power 2.6W
Quiescent Current 6mA
Nominal Supply Current 8mA
Number of Channels 2
Power Supplies 5V
Operating Supply Voltage 5V
Output Type 2-Channel (Stereo) with Stereo Headphones
Pin Count 24
Base Part Number TPA0112
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology CMOS
Max Power Dissipation 2.7W
Subcategory Audio/Video Amplifiers
HTS Code 8542.33.00.01
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Class AB
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Feature Depop, Differential Inputs, Input Multiplexer, Mute, Shutdown, Thermal Protection, Volume Control
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Weight 98.08935mg
Number of Pins 24
Package / Case 24-TSSOP (0.173, 4.40mm Width) Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
