TPA005D14DCA
RoHS
RoHS compliant
RoHS compliantPackage 48-TFSOP (0.240, 6.10mm Width) Exposed Pad
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
GULL WING ROHS3Compliant Contains Lead Surface Mount Amplifier IC Class D -40C~125C TA 20kHz 20dB 2W
PDF
/
Inventory: 5726
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Width 6.1mm
Length 12.5mm
Height Seated (Max) 1.2mm
Technical
Harmonic Distortion 0.5%
Max Output Power x Channels @ Load 2W x 2 @ 4 Ω; 50mW x 2 @ 32 Ω
Max Output Power 2W
Gain 20 dB
Bandwidth 20 kHz
Supply Type Single
Output Power 2W
Quiescent Current 25mA
Nominal Supply Current 25mA
Number of Channels 2
Power Supplies 5V
Operating Supply Voltage 5V
Output Type 2-Channel (Stereo) with Stereo Headphones
Qualification Status Not Qualified
Pin Count 48
Base Part Number TPA005
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Terminal Pitch 0.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Max Power Dissipation 5.6W
Subcategory Audio/Video Amplifiers
HTS Code 8542.33.00.01
Type Class D
ECCN Code EAR99
Number of Terminations 48
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Feature Depop, Differential Inputs, Mute, Short-Circuit and Thermal Protection, Shutdown
Packaging Tube
Operating Temperature -40°C~125°C TA
Physical
Weight 209.304529mg
Number of Pins 48
Package / Case 48-TFSOP (0.240, 6.10mm Width) Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
