TAS5708PHP
RoHS
RoHS compliant
RoHS compliantPackage 48-PowerTQFP
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
8542.33.00.01 TAS5708 Tray Depop Digital Inputs I2C I2S Mute Short-Circuit and Thermal Protection Shutdown Volume Control audio amplifier 24V 1mm 20.2W x 2 @ 8Ohm 77mA
PDF
/
Buying Options
Total Price: USD $1.07
Unit Price: USD $1.07445
≥1 USD $1.07445
≥10 USD $0.8816
≥100 USD $0.85405
≥500 USD $0.8265
≥1000 USD $0.79895
Inventory: 1562
Minimum: 1
-
+
Technical Details
Physical
Number of Pins 48
Surface Mount YES
Package / Case 48-PowerTQFP
Mounting Type Surface Mount
Weight 134.490138mg
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1mm
Width 7mm
Length 7mm
Height 1.2mm
Technical
Max Output Power x Channels @ Load 20.2W x 2 @ 8 Ω
Min Supply Voltage (DC) 3V
Dual Supply Voltage 24V
Max Output Power 20.2W
Supply Type Quad
Output Power 20W
Max Supply Current 77mA
Power Dissipation 5W
Nominal Supply Current 77mA
Number of Channels 2
Power Supplies 3.312/18V
Supply Voltage-Max (Vsup) 3.6V
Output Type 2-Channel (Stereo)
Pin Count 48
Base Part Number TAS5708
Terminal Pitch 0.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Voltage - Supply 10V~26V
Max Power Dissipation 5W
Subcategory Audio/Video Amplifiers
HTS Code 8542.33.00.01
Additional Feature ALSO REQUIRES 3.3V DIGITAL SUPPLY
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Class D
ECCN Code EAR99
Number of Terminations 48
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Feature Depop, Digital Inputs, I2C, I2S, Mute, Short-Circuit and Thermal Protection, Shutdown, Volume Control
JESD-609 Code e4
Packaging Tray
Operating Temperature 0°C~85°C TA
