TAS5614PHDR
RoHS
RoHS compliant
RoHS compliantPackage 64-TQFP Exposed Pad
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
8542.33.00.01 TAS5614 Tape & Reel (TR) Depop Digital Inputs Short-Circuit and Thermal Protection Shutdown audio amplifier 10.8V 1mm 300W x 1 @ 2Ohm; 200W x 2 @ 3Ohm 150W
PDF
/
Buying Options
Total Price: USD $18.05
Unit Price: USD $18.053688
≥1 USD $18.053688
≥200 USD $7.203882
≥500 USD $6.963622
≥1000 USD $6.844148
Inventory: 1436
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status NRND (Last Updated: 1 week ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 64-TQFP Exposed Pad
Number of Pins 64
Technical
Operating Temperature 0°C~70°C TA
Packaging Tape & Reel (TR)
Series PurePath? HD
JESD-609 Code e4
Feature Depop, Digital Inputs, Short-Circuit and Thermal Protection, Shutdown
Pbfree Code yes
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 5A (24 Hours)
Number of Terminations 64
ECCN Code EAR99
Type Class D
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
HTS Code 8542.33.00.01
Subcategory Audio/Video Amplifiers
Voltage - Supply 18V~38V
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.8mm
Base Part Number TAS5614
Pin Count 64
Output Type 1-Channel (Mono) or 2-Channel (Stereo)
Supply Voltage-Max (Vsup) 13.2V
Power Supplies 1236V
Supply Voltage-Min (Vsup) 10.8V
Number of Channels 2
Output Power 150W
Power Supply Rejection Ratio (PSRR) 80dB
Max Output Power 300W
Max Output Power x Channels @ Load 300W x 1 @ 2 Ω; 200W x 2 @ 3 Ω
Harmonic Distortion 0.03%
Dimensions
Height 1.2mm
Length 14mm
Width 14mm
Thickness 1mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
