TAS5424ATDKDQ1
RoHS
RoHS compliant
RoHS compliantPackage 44-BSSOP (0.433, 11.00mm Width) Exposed Pad
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
8542.33.00.01 TAS5424 Tube Depop Differential Inputs I2C Mute Short-Circuit and Thermal Protection Shutdown audio amplifier 8V 3.5mm 116W x 2 @ 2Ohm 58W x 4 @ 4Ohm 300mA
PDF
/
Buying Options
Total Price: USD $195.75
Unit Price: USD $195.7475
≥1 USD $195.7475
≥10 USD $175.49825
Inventory: 907
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 3.5mm
Width 11mm
Length 15.9mm
Height 3.6mm
Technical
Max Output Power x Channels @ Load 116W x 2 @ 2 Ω 58W x 4 @ 4 Ω
Dual Supply Voltage 14.4V
Max Output Power 116W
Gain 32 dB
Power Supply Rejection Ratio (PSRR) 75dB
Voltage Gain 32dB
Supply Type Dual
Common Mode Rejection Ratio 60 dB
Output Power 28W
Quiescent Current 240mA
Power Dissipation 80W
Nominal Supply Current 300mA
Number of Channels 4
Supply Voltage-Min (Vsup) 8V
Supply Voltage-Max (Vsup) 22V
Output Type 4-Channel (Quad)
Pin Count 44
Base Part Number TAS5424
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 245
Terminal Form GULL WING
Voltage - Supply 8V~22V
Max Power Dissipation 80W
Subcategory Audio/Video Amplifiers
HTS Code 8542.33.00.01
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Class D
ECCN Code EAR99
Number of Terminations 44
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Feature Depop, Differential Inputs, I2C, Mute, Short-Circuit and Thermal Protection, Shutdown
JESD-609 Code e4
Series Automotive, AEC-Q100
Packaging Tube
Operating Temperature -40°C~105°C TA
Physical
Number of Pins 44
Surface Mount YES
Package / Case 44-BSSOP (0.433, 11.00mm Width) Exposed Pad
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
