TAS5186DDVG4
RoHS
RoHS compliant
RoHS compliantPackage 44-TSSOP (0.244, 6.20mm Width) Exposed Pad
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
GULL WING ROHS3Compliant Contains Lead Surface Mount Amplifier IC Class D 0C~125C TJ 60W 22mA 60W x 1 @ 3Ohm; 30W x 5 @ 6Ohm
PDF
/
Buying Options
Total Price: USD $6.48
Unit Price: USD $6.476153
≥1 USD $6.476153
≥10 USD $6.109574
≥100 USD $5.763752
≥500 USD $5.437498
≥1000 USD $5.129718
Inventory: 1510
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 6.1mm
Length 14mm
Height Seated (Max) 1.2mm
Technical
Harmonic Distortion 10%
Max Output Power x Channels @ Load 60W x 1 @ 3 Ω; 30W x 5 @ 6 Ω
Dual Supply Voltage 28V
Max Output Power 60W
Supply Type Triple
Output Power 60W
Nominal Supply Current 22mA
Number of Channels 6
Supply Voltage-Min (Vsup) 10.8V
Power Supplies 1240V
Supply Voltage-Max (Vsup) 13.2V
Output Type 6-Channel
Pin Count 44
Base Part Number TAS5186
Terminal Pitch 0.635mm
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 10.8V~13.2V
Subcategory Audio/Video Amplifiers
HTS Code 8542.33.00.01
Additional Feature IT ALSO REQUIRES 0V TO 40V SUPPLY
Type Class D
ECCN Code EAR99
Number of Terminations 44
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
Feature Digital Inputs, Short-Circuit and Thermal Protection, Shutdown
Series PurePath Digital?
Packaging Tube
Operating Temperature 0°C~125°C TJ
Physical
Number of Pins 44
Package / Case 44-TSSOP (0.244, 6.20mm Width) Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
