TAS5112DFDR
RoHS
RoHS compliant
RoHS compliantPackage 56-TFSOP (0.240, 6.10mm Width) Exposed Pad
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
GULL WING ROHS3Compliant Contains Lead Surface Mount Amplifier IC Class D 0C~70C TA 20kHz 62W 5mA
PDF
/
Buying Options
Total Price: USD $8.6
Unit Price: USD $8.59845
≥1 USD $8.59845
≥10 USD $7.05565
≥100 USD $6.83525
≥500 USD $6.61485
≥1000 USD $6.39445
Inventory: 13596
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 6.1mm
Length 14mm
Height Seated (Max) 1.2mm
Technical
Harmonic Distortion 10%
Max Output Power x Channels @ Load 62W x 2 @ 6 Ω
Dual Supply Voltage 29.5V
Max Output Power 62W
Bandwidth 20 kHz
Supply Type Triple
Output Power 62W
Power Dissipation 4.5W
Nominal Supply Current 5mA
Number of Channels 2
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 3.6V
Output Type 2-Channel (Stereo)
Pin Count 56
Base Part Number TAS5112
Terminal Pitch 0.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 16V~25.5V
Max Power Dissipation 4.5W
Subcategory Audio/Video Amplifiers
HTS Code 8542.33.00.01
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Class D
ECCN Code EAR99
Number of Terminations 56
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
Feature Depop, Digital Inputs, Mute, Short-Circuit and Thermal Protection, Shutdown
JESD-609 Code e4
Series PurePath Digital?
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C TA
Physical
Weight 236.888615mg
Number of Pins 56
Package / Case 56-TFSOP (0.240, 6.10mm Width) Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
