TAS5111DAD
RoHS
RoHS compliant
RoHS compliantPackage 32-TSSOP (0.240, 6.10mm Width) Exposed Pad
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
8542.33.00.01 TAS5111 Tube Digital Inputs Mute Short-Circuit and Thermal Protection Shutdown audio amplifier 3V 1.15mm 93W x 1 @ 4Ohm 1mA
PDF
/
Buying Options
Total Price: USD $3.32
Unit Price: USD $3.31835
≥1 USD $3.31835
≥10 USD $2.7227
≥100 USD $2.63815
≥500 USD $2.55265
≥1000 USD $2.46715
Inventory: 1357
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.15mm
Width 6.2mm
Length 11mm
Height 1.2mm
Technical
Harmonic Distortion 10%
Max Output Power x Channels @ Load 93W x 1 @ 4 Ω
Dual Supply Voltage 29.5V
Max Output Power 93W
Bandwidth 20 kHz
Supply Type Triple
Output Power 93W
Nominal Supply Current 1mA
Number of Channels 2
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 3.6V
Output Type 1-Channel (Mono)
Pin Count 32
Base Part Number TAS5111
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~3.6V
Subcategory Audio/Video Amplifiers
HTS Code 8542.33.00.01
Additional Feature IT ALSO REQUIRES 16V TO 30.5V SUPPLY
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Class D
ECCN Code EAR99
Number of Terminations 32
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Last Time Buy
Feature Digital Inputs, Mute, Short-Circuit and Thermal Protection, Shutdown
JESD-609 Code e4
Series PurePath Digital?
Packaging Tube
Operating Temperature 0°C~70°C TA
Physical
Weight 181.096754mg
Number of Pins 32
Package / Case 32-TSSOP (0.240, 6.10mm Width) Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status LIFEBUY (Last Updated: 5 days ago)
