TAS5110DAP
RoHS
RoHS compliant
RoHS compliantPackage 32-PowerTSSOP (0.240, 6.10mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
GULL WING ROHS3Compliant Lead Free Surface Mount Amplifier IC Class D 0C~70C TA 50W 2mA 50W x 2 @ 6Ohm
PDF
/
Buying Options
Total Price: USD $16.75
Unit Price: USD $16.7466
≥1 USD $16.7466
≥10 USD $13.7408
≥100 USD $13.3114
≥500 USD $12.882
≥1000 USD $12.4526
Inventory: 7099
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 6.1mm
Length 11mm
Technical
Harmonic Distortion 10%
Max Output Power x Channels @ Load 50W x 2 @ 6 Ω
Max Output Power 50W
Supply Type Single
Output Power 50W
Nominal Supply Current 2mA
Number of Circuits 2
Number of Channels 2
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3.3V
Output Type 2-Channel (Stereo)
Qualification Status Not Qualified
Pin Count 32
Base Part Number TAS5110
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~3.6V
Subcategory Audio/Video Amplifiers
Type Class D
ECCN Code EAR99
Number of Terminations 32
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Feature Digital Inputs, Mute, Short-Circuit and Thermal Protection, Shutdown
Series Equibit?
Packaging Tube
Operating Temperature 0°C~70°C TA
Physical
Number of Pins 32
Package / Case 32-PowerTSSOP (0.240, 6.10mm Width)
Mounting Type Surface Mount
Mount Surface Mount
