TAS2770YFFR

Texas Instruments
RoHS
RoHS RoHS compliant
Package 30-UFBGA, DSBGA
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description BALL ROHS3Compliant Surface Mount Active audio amplifier -40C~85C 20kHz 15.4W 20W x 1 @ 4Ohm
PDF
/
Buying Options
Total Price: USD $4.83
Unit Price: USD $4.83265
≥1 USD $4.83265
≥10 USD $3.9653
≥100 USD $3.8418
≥500 USD $3.71735
≥1000 USD $3.59385
Inventory: 1855
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Thickness 375μm
Width 2.59mm
Length 2.2mm
Height 625μm

Technical

Max Output Power x Channels @ Load 20W x 1 @ 4 Ω
Bandwidth 20 kHz
Output Power 15.4W
Number of Channels 1
Supply Voltage-Min (Vsup) 1.65V
Supply Voltage-Max (Vsup) 1.95V
Output Type 1-Channel (Mono)
Base Part Number TAS2770
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.4mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form BALL
Terminal Position BOTTOM
Voltage - Supply 1.65V~1.95V 4.5V~16V
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Type Class D
Number of Terminations 30
Moisture Sensitivity Level (MSL) 1
Part Status Active
Pbfree Code yes
Feature I2C, I2S, Mute, PWM, Short-Circuit and Thermal Protection, Volume Control
JESD-609 Code e1
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C

Physical

Number of Pins 30
Surface Mount YES
Package / Case 30-UFBGA, DSBGA
Mounting Type Surface Mount

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 16 Weeks
