LM4951SDX/NOPB
RoHS
RoHS compliant
RoHS compliantPackage 10-WDFN Exposed Pad
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
8542.33.00.01 LM4951 Tape & Reel (TR) Depop Shutdown Thermal Protection audio amplifier 2.7V 750mum 1.8W x 1 @ 8Ohm 4.5mA
PDF
/
Buying Options
Total Price: USD $1.34
Unit Price: USD $1.34235
≥1 USD $1.34235
≥10 USD $1.102
≥100 USD $1.0678
≥500 USD $1.03265
≥1000 USD $0.99845
Inventory: 10476
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 750μm
Width 4mm
Length 4mm
Height 800μm
Technical
Harmonic Distortion 1%
Max Output Power x Channels @ Load 1.8W x 1 @ 8 Ω
Max Output Power 1.8W
Power Supply Rejection Ratio (PSRR) 66dB
Input Offset Voltage (Vos) 30mV
Supply Type Single
Output Power 1.8W
Supply Current-Max 4.5mA
Number of Channels 1
Supply Voltage-Min (Vsup) 2.7V
Supply Voltage-Max (Vsup) 9V
Operating Supply Voltage 5V
Output Type 1-Channel (Mono)
Base Part Number LM4951
Terminal Pitch 0.8mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 2.7V~9V
Subcategory Audio/Video Amplifiers
HTS Code 8542.33.00.01
Terminal Finish Matte Tin (Sn)
Type Class AB
ECCN Code EAR99
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Depop, Shutdown, Thermal Protection
JESD-609 Code e3
Series Boomer?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 10
Package / Case 10-WDFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 6 Weeks
