LM49370RLX/NOPB
RoHS
RoHS compliant
RoHS compliantPackage 49-WFBGA, DSBGA
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
BALL ROHS3Compliant Lead Free Surface Mount Amplifier IC Class D -40C~85C TA 86dB 1.2W 11.5mA
PDF
/
Buying Options
Total Price: USD $4.02
Unit Price: USD $4.0185
≥1 USD $4.0185
≥10 USD $3.29745
≥100 USD $3.19485
≥500 USD $3.0913
≥1000 USD $2.9887
Inventory: 1513
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3.88mm
Length 3.88mm
Height Seated (Max) 0.725mm
Technical
Max Output Power x Channels @ Load 1.2W x 1 @ 8 Ω; 52mW x 2 @ 16 Ω
Dual Supply Voltage 5V
Number of A/D Converters 1
Max Output Power 1.2W
Power Consumption 45.5mW
Power Supply Rejection Ratio (PSRR) 86dB
Voltage Gain 52.5dB
Supply Type Quint
Output Power 1.2W
Nominal Supply Current 11.5mA
Output Type 1-Channel (Mono) with Mono and Stereo Headphones
Base Part Number LM49370
Terminal Pitch 0.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Voltage - Supply 2.5V~5.5V
Subcategory Audio/Video Amplifiers
Terminal Finish TIN SILVER
Type Class D
ECCN Code EAR99
Number of Terminations 49
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature 3D, Depop, I2C, I2S, Microphone, Mute, PCM, Shutdown, SPI, Standby, Volume Control
JESD-609 Code e2
Series Boomer?, PowerWise?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 49
Package / Case 49-WFBGA, DSBGA
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Silver, Tin
