LM4910MAX/NOPB
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
GULL WING ROHS3Compliant Surface Mount Obsolete Amplifier IC Class AB -40C~85C TA 65dB 0.035W 6mA
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.264
≥1 USD $0.264
Inventory: 1650
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Height Seated (Max) 1.753mm
Technical
Harmonic Distortion 1%
Max Output Power x Channels @ Load 35mW x 2 @ 32 Ω
Max Output Power 35mW
Power Supply Rejection Ratio (PSRR) 65dB
Output Power 0.035W
Supply Current-Max 6mA
Number of Channels 2
Supply Voltage-Min (Vsup) 2.2V
Power Supplies 2.6/5V
Supply Voltage-Max (Vsup) 5.5V
Output Type Headphones, 2-Channel (Stereo)
Qualification Status Not Qualified
Pin Count 8
Base Part Number LM4910
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 1.27mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.2V~5.5V
Subcategory Audio/Video Amplifiers
Terminal Finish Matte Tin (Sn)
Type Class AB
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Depop, Shutdown, Thermal Protection
JESD-609 Code e3
Series Boomer?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
