LM4892LDX
RoHS
RoHS compliant
RoHS compliantPackage 10-WFDFN Exposed Pad
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
NO LEAD ROHS3Compliant Lead Free Surface Mount audio amplifier -40C~85C TA 80kHz 1W 4mA
PDF
/
Inventory: 7638
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 3mm
Length 4mm
Height Seated (Max) 0.8mm
Technical
Harmonic Distortion 2%
Max Output Power x Channels @ Load 1W x 1 @ 8 Ω; 90mW x 1 @ 32 Ω
Max Output Power 1W
Bandwidth 80 kHz
Output Power 1W
Quiescent Current 4mA
Number of Channels 1
Supply Voltage-Min (Vsup) 2.2V
Power Supplies 2.6/5V
Supply Voltage-Max (Vsup) 5.5V
Output Type 1-Channel (Mono) with Mono Headphones
Qualification Status Not Qualified
Base Part Number LM4892
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) 235
Terminal Form NO LEAD
Terminal Position DUAL
Voltage - Supply 2.2V~5.5V
Subcategory Audio/Video Amplifiers
HTS Code 8542.33.00.01
Terminal Finish Tin/Lead (Sn85Pb15)
Type Class AB
ECCN Code EAR99
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Depop, Shutdown, Thermal Protection
JESD-609 Code e0
Series Boomer?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 10
Package / Case 10-WFDFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
