LM4820M-6
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
GULL WING Non-RoHS Compliant Contains Lead Surface Mount Amplifier IC Class AB -40C~85C TA 66dB 1W 4mA
PDF
/
Buying Options
Total Price: USD $0.61
Unit Price: USD $0.6072
≥1 USD $0.6072
Inventory: 1685
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Series Boomer?
Feature Depop, Shutdown, Thermal Protection
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type Class AB
Voltage - Supply 2V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Terminal Pitch 1.27mm
Base Part Number LM4820
Output Type 1-Channel (Mono)
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 2V
Number of Channels 1
Quiescent Current 4mA
Output Power 1W
Power Supply Rejection Ratio (PSRR) 66dB
Max Output Power 1W
Max Output Power x Channels @ Load 1W x 1 @ 8 Ω
Harmonic Distortion 2%
Dimensions
Height Seated (Max) 1.753mm
Length 4.902mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
