LM4780TA/NOPB
RoHS
RoHS compliant
RoHS compliantPackage TO-220-27 Formed Leads
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
EAR99 LM4780 Tube Depop Mute Short-Circuit and Thermal Protection audio amplifier 28V 15.6972mm 60W x 2 @ 8Ohm 1muA
PDF
/
Buying Options
Total Price: USD $134.91
Unit Price: USD $134.910277
≥1 USD $134.910277
≥10 USD $127.273847
≥100 USD $120.069669
≥500 USD $113.27327
≥1000 USD $106.861572
Inventory: 1395
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4.4958mm
Length 29.21mm
Height 15.6972mm
Technical
Load Impedance 4Ohm
Max Output Power x Channels @ Load 60W x 2 @ 8 Ω
Input Bias Current 1μA
Dual Supply Voltage 28V
Min Dual Supply Voltage 10V
Max Output Power 60W
Max Dual Supply Voltage 42V
Gain 34 dB
Power Supply Rejection Ratio (PSRR) 120dB
Voltage Gain 115dB
Gain Bandwidth Product 8MHz
Bandwidth 8MHz
Input Offset Voltage (Vos) 10mV
Supply Type Dual, Single
Common Mode Rejection Ratio 85 dB
Slew Rate 19 V/μs
Output Power 60W
Quiescent Current 110mA
Power Dissipation 125W
Nominal Supply Current 110mA
Number of Channels 2
Power Supplies +-35V
Output Type 2-Channel (Stereo)
Base Part Number LM4780
Number of Functions 1
Terminal Position ZIG-ZAG
Voltage - Supply 20V~84V ±10V~42V
Max Power Dissipation 125W
Subcategory Audio/Video Amplifiers
Terminal Finish Matte Tin (Sn)
Type Class AB
ECCN Code EAR99
Number of Terminations 27
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Feature Depop, Mute, Short-Circuit and Thermal Protection
JESD-609 Code e3
Series Overture?
Packaging Tube
Operating Temperature -20°C~85°C TA
Physical
Weight 9.071847g
Number of Pins 27
Package / Case TO-220-27 Formed Leads
Mounting Type Through Hole
Mount Through Hole
Alternative Model
