LM4755TSX/NOPB
RoHS
RoHS compliant
RoHS compliantPackage TO-263-10 (9 Leads + Tab)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
e3 LM4755 Tape & Reel (TR) Mute Short-Circuit and Thermal Protection audio amplifier 9V 4.572mm 11W x 2 @ 4Ohm 10mA
PDF
/
Buying Options
Total Price: USD $2.38
Unit Price: USD $2.376
≥1 USD $2.376
≥10 USD $2.13136
≥100 USD $2.010976
≥500 USD $1.713272
≥1000 USD $1.60871
Inventory: 1145
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 4.572mm
Width 8.687mm
Length 10.16mm
Height 4.8mm
Technical
Harmonic Distortion 10%
Max Output Power x Channels @ Load 11W x 2 @ 4 Ω
Max Output Power 11W
Power Supply Rejection Ratio (PSRR) 50dB
Voltage Gain 34dB
Bandwidth 65 kHz
Supply Type Single
Output Power 11W
Power Dissipation 62.5W
Nominal Supply Current 10mA
Number of Channels 2
Supply Voltage-Min (Vsup) 9V
Output Type 2-Channel (Stereo)
Pin Count 4
Base Part Number LM4755
Number of Functions 1
Peak Reflow Temperature (Cel) 245
Terminal Form GULL WING
Voltage - Supply 9V~32V
Technology BIPOLAR
Max Power Dissipation 62.5W
Subcategory Audio/Video Amplifiers
Terminal Finish Matte Tin (Sn)
Type Class AB
Number of Terminations 9
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Feature Mute, Short-Circuit and Thermal Protection
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -20°C~80°C
Physical
Number of Pins 9
Surface Mount YES
Package / Case TO-263-10 (9 Leads + Tab)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
Alternative Model
